Product Description
Advanced, capable, and strong Don’t let the good looks fool you. WARN have packed the ZEON 8-S winch with all the performance features off-roaders said they needed most. From a heat-dissipating brake down to an incredibly smooth planetary gear train, this winch is ready to hit the trail. The 8,000 lb. pulling capacity, combined with a fast line speed make this winch the perfect choice for Jeep and SUV trail rigs.8,000 lb. (3630 kg) single-line pulling capacity Includes 100′ of 3/8″ WARN Spydura synthetic rope, which includes a temperature-resistant sleeve on the first layer, a ballistic nylon sliding sleeve for abrasion resistance, and a polished aluminum hawse fairlead.
Convertible control pack can be attached to the winch or remotely mounted, allowing for various winch mounting options and looks (Relocation kit required and sold separately*). Satin-black powder-coated finish with stainless steel fasteners and clutch lever looks great and inhibits corrosion. Improved winch sealing to keep the elements out.Large diameter winch drum reduces rope wear, is light weight, and has an integrated rope anchor for easy rope installation.Backed by the WARN Limited Lifetime Warranty
*Control Pack Relocation Kit. Required to mount control box remotely from winch. PN 89970 (Short kit), PN 89960 (Long kit)
ZEON 8-S SPECS
Rated line pull: 8000 lbs. (3630 kg) single-line Motor: 12V DC, series wound Electrical controls: Contactor Remote Control: Remote switch, 12′ (3.7m) lead Geartrain: 3-stage planetary Gear ratio: 162:1
Clutch (freespooling): Rotating ring gear Brake: Automatic mechanical cone Drum diameter/Length: 3.15″/9.0″ (80mm/229mm)
Weight (kit shipping): 75 lbs. (34 kg)Rope: 3/8″ x 100′ (9.5mm x 30.5m) Spydura synthetic Fairlead: Hawse Recommended Battery: 650 CCA minimum for winching Battery leads: 25mm gauge, 72″ (1.83m)
Finish: Satin-black powder coat Warranty: Limited lifetime
12V DC PERFORMANCE SPECS
Line PullLbs.(Kgs.) Line SpeedFT./min(M/min.) Motor Current Pull by layerlayer/Lbs(Kgs.)0 42 (12.8) 63 amps 1/8000 (3629)2000 (910) 17.2 (5.2) 167 amps 2/6777 (3074)4000 (1810) 11.7 (3.6) 255 amps 3/5878 (2666)6000 (2720) 8.5 (2.6) 335 amps 4/5189 (2353)8000 (3630) 6.2 (1.9) 413 amps
Above performance specs are based on first layer of drum
